Integral Blind and Insulated Blind Windows

Clarity At The Flick Of A Switch

Unique and unrivaled, Clarity allows discreet observation and privacy, while maintaining a smart and modern feel.  Switchable Glass at its very BEST!

It couldn’t be easier. With a simple on/off switch, Clarity applies an electrical charge to the glass, changing its state from opaque to clear. Releasing the switch, returns it from clear to opaque instantaneously. While transparent, you enjoy the uninterrupted views from your window or door, then when privacy is needed, the frosted state acts just like a blind, providing seclusion and security.

Clarity can be supplied in either single pane form or as a double glazed sealed unit. When double glazed, it also offers the benefits of improved thermal performance, offering greater control and comfort within any room.

The Benefits of CLARITY are Clear

  • Instant control of privacy
  • High UV protection
  • Superior Light Transmittance
  • Low Haze in off-axis viewing angle
  • Flexible production size
  • Can be retro-fitted
  • Single Glazed Laminate glass panels or Double Glazed Sealed Units available
  • Fire rated glass available
  • Multiple shapes available
  • Over 50,000 hours of testing completed

Manufacturing & Technical Information

Clarity is manufactured using the latest PDLC (Polymer Dispersed Liquid Crystal) film which is laminated between two panes of glass, including fire rated panes.

CLARITY LCD FILM CONSISTS OF:

  • PET Protective Layer / ITO / GEL
  • Panels are available in sizes up to max size 35 sq ft.

Technical Information

Feature Specification
Visible Light Transmission ON >89%  |  OFF>=2%
Haze ON < 4%   |  OFF>=91%
Viewing Angle of Screen ON <160 degrees
UV Blocking >99%
Operating Voltage ON  60V Ac
Response Time OFF>ON  <10ms

ON>OFF  <200ms

Power Consumption <5 W/sqm
Color White when OFF
Working Temperature -30°C to 50°C
Storage Temperature -30°C to 70°C
Life Span ON > 15 Years
Switch Life > 2 million times

Ideal for the Following Areas

  • Hotels
  • Banks
  • Security areas
  • Healthcare facilities
  • Residential homes
  • Schools
  • Hospitality areas
  • Retail Shops and more

FAQs

What is Clarity?

Clarity is electric switchable privacy glass with LCD technology.

How does it work?

When the power is on, the liquid crystal molecules align, which gives you visibility. When the power is off the liquid crystals are dispersed, which gives you privacy.

How clear is it when turned on?

Clarity has less than 5% haze factor.

How long will it last?

Clarity comes with a 5-year warranty and has a life expectancy of 80,000 hours which equates to almost 10 years of continuous usage.

Clarity

At the Flick of a Switch
